132kW Wood Crushing Machine

Product Details:
Place of Origin: China
Brand Name: ThoYu
Certification: CE
Model Number: TYFS-1300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Strong wooden pallet for global shipping
Delivery Time: 10-120 working days
Payment Terms: L/C, D/A, Western Union, MoneyGram
Supply Ability: 20 sets per month

Detail Information

Product Name: Hammer Integrated Wood Crushing Machine Feed Size: 1300*400 Mm
Motor Power: 132 KW Feed Power: 7.5*2 KW
Output Power: 3 KW Rotating Speed: 510 R/min
High Light:

132kW Wood Crushing Machine


Hammer Integrated Wood Crushing Machine


Hammer Integrated Wood Crusher

Product Description

Templates Wooden Crates Hammer Integrated Wood Crushing Machine


Hammer integrated wood crushing machine is upgraded equipment based on the equipment of the template crusher itself. The device combines the advantages of a template crusher and abandons the shortcomings of the template crusher that cannot crush large pieces of material.


The machine function is more powerful, stable, and reliable, the material has wide applicability, the function is outstanding, the operation and repair are convenient. 132 kW wood crushing machine is a green and low-carbon efficient equipment.


Hammer integrated wood crushing machine application


The hammer integrated wood crushing machine is suitable for a variety of materials such as waste containers, templates, plates, branches, wooden crates, pallets, and so on.

132kW Wood Crushing Machine 0

Hammer integrated wood crushing machine model parameters


Model Feed Size (mm) Motor Power (kW) Feed Power (kW) Output Power (kW) Rotating Speed (r/min) Capacity (t/h) Dimensions (mm)
TYFS-1000 1000*400 110 5.5*2 3 510 15-20 6000*2150*1750
TYFS-1300 1300*400 132 7.5*2 3 510 20-25 6000*2350*1750
TYFS-1500 1500*400 160 11*2 4 365 25-35 6000*2950*1950
TYFS-1600 1600*400 200 15*2 4 365 35-45 6000*2950*1950


132kW Wood Crushing Machine 1


Hammer integrated wood crushing machine working principle


The hammer integrated wood crushing machine is mainly based on impact energy to complete the crushing of wood operations. When the hammer wood crusher works, the motor drives the rotor to rotate at a high speed, and the wood evenly enters the integrated wood crusher cavity. The high-speed rotating hammer head impacts, shears, and tears the wood to be broken, under the action of its own gravity, the wood rushes from the high-speed rotating hammer head to the baffle plate and the screen strip in the frame body. In the lower part of the rotor, a sieve plate is provided. The wood less than the mesh size in the crushed wood is discharged through the sieve plate, and the wood larger than the mesh size is retained in the sieve. The board continues to be hit and ground by the hammer.


132kW Wood Crushing Machine 2
