Disc Type Husky Tree Log Wood Chip Crusher Wood Crushing Machine

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Strong wooden pallet for global shipping Delivery Time : 10-60 working days
Payment Terms : L/C, D/A, Western Union, MoneyGram Supply Ability : 60 sets per month
Place of Origin: China Brand Name: ThoYu
Certification: CE Model Number: TYXP1000-A

Detail Information

Product Name: Tree Log Wood Chips Crushing Machine Dia. Of Cutterhead: 1000 Mm
Length Of Finished Chips: 2-50 Mm Thickness Of Finished Chips: 2-15 Mm
Size Of Feeding Port: 300x300 Mm Working Capacity: 5-7 T/h
High Light:

Log Wood Chip Crusher


Tree Wood Chip Crusher


37kw wood chip crushing machine

Product Description

Disc Type Tree Log Wood Chips Crushing Machine

Introduction of Disc Type Tree Log Wood Chips Crushing Machine

TYXP-A series disc tree log wood chips crushing machine adopts low or high voltage motor, heavy-duty models driven by V-belt or directly connect to the motor, feeding direction could be horizontal or oblique, chips discharged from top or bottom.

The length of finished chips is adjustable freely in a specific range.

TYXP-A disc tree log wood chips crushing machine consists of chassis, cutter, feeding port, shell, motor, and cabinet control, which is suitable for log ≤300mm (Dia.) and branches, applicable to paper-making factory, the forestry industry, and other wood processing factories.

Tree Log Wood Chips Crushing Machine Technical Parameters

Model TYXP1000-A TYXP1200-A TYXP1400-A
Dia. of the cutter head 1000 mm 1200 mm 1400 mm
Rotary speed of cutter head 610 rpm 490 rpm 490 rpm
Length of finished chips 2-50 mm 2-50 mm 2-50 mm
The thickness of finished chips 2-15 mm 2-15 mm 2-15 mm
Feeding way Horizontal Horizontal Horizontal
Size of the feeding port 300x300 mm 335x335 mm 360x360 mm
Working capacity 5-7 t/h 7-10 t/h 10-15 t/h
Power of motor 30-37 kW 37-45 kW 45-55 kW
Dia. of max wood allowed 250 mm 300 mm 350 mm
Discharging way inclined top inclined top bottom
Weight 1600 kg 2700 kg 3300 kg
Dimension 2200x850x1500 mm 2400x1100x1600 mm 2600x1250x1750 mm

Disc Type Husky Tree Log Wood Chip Crusher Wood Crushing Machine 0



















Tree Log Wood Chips Crushing Machine Features

  • 1. 2-layers structure inside.
  • 2. Use the new type of material to achieve sound-proofing.
  • 3. No vibration, very low noise, the entire machine is made durable, the working capacity is 175% compared with traditional wood powder machines.
  • 4. Equipped new adjustable screen, it makes the powder fineness is controllable, fineness range 30-325 mesh and all powder is even.
  • 5. Equipped drum screen, could be replaced to be different size screen to control the fineness, the powder qualification reaches to 100%!

tree log wood sawdust crushing machine
