New Presswood Pallet Machine for Recycling Wood Waste
Introduction of New Presswood Pallet Machine for Recycling Wood Waste
New presswood pallet machine for recycling wood waste in Italy is designed to produce presswood pallets, which using leftover wood materials. ThoYu offers turnkey solutions for new presswood pallet machine for recycling wood waste in Italy. We are one of the leading project suppliers for new presswood pallet machine for recycling wood waste in Italy. And we work closely with our customers to fulfill their specific needs for a customized solution. We specialize in the fabrication of these machines for a decade. And we are in a leading position in the field of new presswood pallet machine for recycling wood waste in Italy. The raw materials are wood sawdust, straw, waste chemical fiber, and other fibers, and so on.
Characteristics of New Presswood Pallet Machine for Recycling Wood Waste in Italy
New presswood pallet machine for recycling wood waste in Italy is vertical structure of four-column hydraulic press machine. And it consists of the frame, oil cylinder, the hydraulic power system and electrical system, and other accessories.
1. Structure.
The frame of new presswood pallet machine for recycling wood waste in Italy adopts the 3-beam 4-column structure with good strength, rigidity, and precision retaining ability.
2. Hydraulic system.
Separate hydraulic systems, with compact structure, small flow resistance, sensitive and reliable work.
Sealed performance is good, easy maintenance, and long service life.
Working pressure is adjustable within the scope of the parameter.
3. Control system.
Control cabinets can be automatic and manual control.
3.1 Automatic control mode: press the automatically start button, then the machine will complete the whole process of presswoood pallet production.
3.2 Manual control mode: manual button can control the mold up and down and unload the presswood pallet.
4. Safe device.
The motor controlling parts equip thermal protectors and breakers. So it can protect the motor will not break when overload and have the protection measures of overload and short circuit.
It has an overflow valve for the rise and fall of the cylinder to ensure overload pressure.
Overpressure protection: the equipment will stop working when the pressure is overset pressure.
Technology Parameters of New Presswood Pallet Machine for Recycling Wood Waste in Italy:
| Model | TY-1250 | TY-1600 |
| Voltage | 220 V/380 V, 50 Hz, three-phase | 220 V/380 V, 50 Hz, three-phase |
| Capacity | 300 pieces/day (24 hours) | 300 pieces/day (24 hours) |
| Power | 75 kW | 75 kW |
| Hydraulic cylinder diameter | 350 mm | 380 mm |
| Hydraulic cylinder quantity | 4 pieces | 4 pieces |
| Pressure | 1250tons (adjustable) | 1600tons (adjustable) |
| Shaping cycle | 350 seconds | 350 seconds |
| Weight | 28 tons | 33tons |
| Dimension | 2000*1400*3500 mm | 2000*1400*3500 mm |
