Fully Automatic Compressed Pallet Injection Molding Machine
Contact Person : Robin
Phone Number : +86-13733828553
WhatsApp : +8613733828553
Minimum Order Quantity : | 1 set | Price : | Negotiation |
---|---|---|---|
Packaging Details : | Strong wooden case | Delivery Time : | 15-45 work days |
Payment Terms : | L/C, D/A, T/T, Western Union, MoneyGram | Supply Ability : | 25 sets per month |
Place of Origin: | China | Brand Name: | ThoYu |
---|---|---|---|
Certification: | CE | Model Number: | TYSL-1000 |
Detail Information |
|||
Product Name: | Compressed Plastic Pallets Molding Machine | Materials: | Plastic Waste |
---|---|---|---|
Process: | Compressing | Product Warranty: | 1 Year |
Condition: | New | Production: | Automatic |
High Light: | Compressed Plastic Pallet Injection Molding Machine,Recycle Plastic Pallet Injection Molding Machine,Waste Plastic Pallet Injection Molding Machine |
Product Description
Compressed Plastic Pallets Molding Machine For Recycle Waste Plastics
Plastics wastes are a growing mountain needing expensive and possibly polluting treatments. So, it makes more sense to invest in their recycling combining in the same operation with two objectives, a safer removal of waste on the one hand and value-added recovery as new raw material on the other hand. Ins and outs must be carefully examined because, surprisingly, recycling process may not always be beneficial.
In order to solve the problem of waste plastic pollution and recycling, after several years of research and testing, our company has explored a solution for recycling waste plastics into pallets, which can use most of the waste plastics for recycling, and can be made into plastics after recycling. Plastic products such as pallets have extremely low requirements for raw materials, no granulation process, and low input cost. The finished plastic products can be recycled and reused repeatedly. It is a new energy-saving and environmentally friendly recycling method for waste plastics.
What materials can be used to make pressed plastic pallets?
Waste plastics, such as PE, PET, HDPE, PP, PVE, etc, which contains of carbonated drink bottles, peanut butter jars, plastic film, and microwavable packaging, etc.
Compressed plastic pallets molding machine parameters
Model | TYSL-1000 |
Pressure | 0-1000 tons (adjustable) |
Hydraulic oil cylinder quantity | 4 pieces |
Pallet density | 850-950 kg/m3 |
Shaping cycle | 120 seconds |
Pressure increasing time | 350 seconds |
Capacity | 240 pcs/ 24 hours |
Power | 18.5 kW |
Weight | 22 tons |
*All specifications and operating instructions accord to OSHA Standard. *Mold and cylinder systems are controlled by PLC programming. *Note: for running the machine, it needs 600 L hydraulic oil before the start. |
Working principle of compressed plastic pallets molding machine
1. Material splitting and selection (if needed)
2. Washing (if needed)
3. Shredding and crushing (if needed)
4. Drying
5. Extruding and pressing
Advantages of the compressed plastic pallets molding machine
1. low cost, reduce 2/3 cost of the injection & blowing machine
2. No pelletizing, reduce the working process and equipment cost
3. automatic production, save labor cost
4. various materials selected, you can use most types of waste plastics to make it.
5. Environment protect
