Pallet Timber Cutting Machine

Product Details:
Place of Origin: China
Brand Name: ThoYu
Certification: CE
Model Number: TY-1250DP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Strong wooden pallet for global shipping
Delivery Time: 15-45 work days
Payment Terms: L/C, D/A, Western Union, MoneyGram
Supply Ability: 40 sets per month

Detail Information

Name: Pallet Block Cutting Saw / Wood Block Cutter Capacity: 5 M3/hour
Max Cut Length: 1250 Mm Max Cut Width: 200 Mm
Max Cut Thickness: 110 Mm Net Weight: 1100 Kg
Color: According To Your Need
High Light:

Pallet Timber Cutting Machine


5m3 hour Timber Cutting Machine


Automatic Timber Block Cutting Machine

Product Description

Pallet Block Cutting Saw  / Wood Block Cutter


Introduction of Pallet Block Cutting Saw  / Wood Block Cutter​


Pallet block cutting saw is suitable for processing shavings pallet blocks, solid woods, multi-layer woods. Pallet block cutting saw is stable, efficient, safe, and simple, and so on. And it is also dominant in wood pallet processing equipment.


Technical Parameters of Pallet Block Cutting Saw / Wood Block Cutter

Model TY-1250DP
Capacity 5 m3/hour
Overall dimension 1960*1560*1360 mm
Main motor power 22 kW
Feeding motor power 1.1 kW
Max cut length 1250 mm
Max cut width 200 mm
Max cut thickness 110 mm
Speed of mainshaft 3000 r/min
Processing accuracy 0.5 mm
Net weight 1100 kg


Pallet Timber Cutting Machine 0

Features of Pallet Block Cutting Saw / Wood Block Cutter

  1. High production efficiency, with cutting 5 m3 in one hour.
  2. The bullet-proof chain is installed at the inlet to prevent the wood chips from rebounding. And the slope is installed at the discharge port, and the discharge is smooth, preventing the wood from flying out.
  3. There is a safety shield on the top of pallet block cutting saw, so it is safer to place the wood.
  4. The whole process is automatic feeding, the upper and lower shaft structure, multi-piece sawing, continuous discharging, so the efficiency is increased by 5-6 times, and the sawing road is thinner than other machines.
  5. Excellent quality motor for long service life.
  6. The multi-blade sawing process is stable, the sawing precision is high, the surface is smooth and flat, no need to re-process, and reducing wood waste.

Pallet Timber Cutting Machine 1

Characteristics of Pallet Block Cutting Saw / Wood Block Cutter

  1. The power-enhanced feeding conveyor is strong and powerful, reducing the labor intensity of workers and making the sawing logs more stable.
  2. Powerful cylinder drives feeding, and low failure rate. High quality imported transmission chain is with durability.
  3. Chain plate/chain feeding, and navigation sheet discharge, is suitable for processing shorter wood. The feeding chain penetrates the machine frame, and the whole chain feeding can cut the shorter wooden side and the sawing is smoother. Pallet block cutting saw can make it more economical than other types of multi-blade saws.
  4. Pallet block cutting saw is fully automatic feeding and unloading, maximizing efficiency, and one-man operation.
  5. The operation greatly saves labor and improves the utilization rate of the wood. When feeding, the wood is pressed up and down, and the cutting is stable.

Pallet Timber Cutting Machine 2


Pallet Timber Cutting Machine 3
