Automatic Pallet Notcher Wood Pallet Notching Machines

Product Description

Automatic Pallet Notcher Wood Pallet Notching Machine

Introduction of Automatic Pallet Notcher Wood Pallet Notching Machine

1. Automatic pallet notcher wood pallet notching machine is perfect for your notching and chamfering requirements. And automatic pallet notcher wood pallet notching machine requires only one person to operate, and with the optional chamfering attachment, it can also be used as a chamfering machine.
2. Automatic pallet notcher wood pallet notching machine has minimal set-up time and four second cycle times. The operator places two to three stringers at a time in the stringer magazine. The stringers are positioned to the left or right end stop. The two palm buttons are then pressed and the first notch pass is made. The material is then slid over to the opposite stop and the process is repeated to make the second notch. Stack the finished product.
3. Automatic pallet notcher wood pallet notching machine belongs to the woodworking machine. And automatic pallet notcher wood pallet notching machine is a kind of special requirements in the production of wooden pallets. Automatic pallet notcher wood pallet notching machine is for wood pallets longitudinal automatic dredging, milling slot, dual-slot open at the same time, and smooth slot with the same size. Automatic pallet notcher wood pallet notching machines are designed to notch new or recycled stringers for 4-way pallets. They feature the extra-tough ThoYu cutting heads.

Characteristics of Automatic Pallet Notcher Wood Pallet Notching Machine

1. Notches 2 x 4's or 4 x 4
2. Standard 1 1/2" notch with radius corners
3. Standard 9 inch notch length
4. 9 inch indexable head
5. Adjustable notch placements from 6 inch to 26 inch
6. Stringer sizes: 36 to 84 inches
7. 15 HP 3 phase 220 V (standard)
8. Rolling Bed
9. Adjustable End Stops
10. Notches 12+ Stringers per minute

Features of Automatic Pallet Notcher Wood Pallet Notching Machine

1. Automatic pallet notcher wood pallet notching machine is a machine to make the notching in the stringer. The length, the lower depth, and the chain advance speed which drag the stringer can be adjusted. The cutting blade is adjustable, can easy to change cutter, and cost-effective. Automatic pallet notcher wood pallet notching machine works in a longitudinal way.
2. Automatic pallet notcher wood pallet notching machine incorporates one stringer feeder for the automatic feeding and with one stacker in the exit. Continuous feeding and automatic discharging platform can double slot opened at the same time, the excavated area smooth without coarse, standard size, and high precision. Notching length is adjustable, and the max notching length is 370 mm.
3. With a solid and simple design, automatic pallet notcher wood pallet notching machine is ready for a non-stop activity with minimum maintenance. Reliable safety protection device, so the worker operation no touch knives with high security.
4. Automatic pallet notcher wood pallet notching machine is suitable for the process of sandpaper/striping and grooving in the production process of American wooden pallets. Automatic pallet notcher wood pallet notching machine is a compact, heavy-duty, and safe machine for your notching needs.

Operation of Automatic Pallet Notcher Wood Pallet Notching Machine

Automatic pallet notcher wood pallet notching machine is started by depressing the start button on the electrical box located on the front of the machine. Next, the operator places one or two boards into the holder's arms and aligns them to the left or right stop. The operator first pushes the handle in front of the holder's arms to move material across the well-guarded cutter area and then pulls it back. Next, the operator slides boards to the alignment stop on the other side and repeats the process. Cutting two boards at a time can yield up to 1800 boards per hour.

Technical Parameters of Automatic Pallet Notcher Wood Pallet Notching Machine

Advantages of Automatic Pallet Notcher Wood Pallet Notching Machine

1. Faster, safer, more profitable automatic pallet notcher wood pallet notching machine from ThoYu - Quality you can depend on every time. Notch your 4-way pallet stringers using ThoYu automatic pallet notcher wood pallet notching machine. And automatic pallet notcher wood pallet notching machine is designed to notch new or recycled stringers for 4-way pallets. It features the extra-tough cutting heads. Automatic pallet notcher wood pallet notching machine produces a flat-bottom notch for your pallet stringers. The various parameters have been optimized to improve the efficiency, and the production capacity of Automatic pallet notcher wood pallet notching machine exceeds 10 times the labor efficiency.
2. Automatic pallet notcher wood pallet notching machine head is composed of an alloy cutter head, and the four faces can be rotated. The cutter head of automatic pallet notcher wood pallet notching machine is well guarded and never exposed to the operator. In addition to a front clamp, a top clamp is included to help hold the material down while it is being notched.
3. Notch new or recycled material or even 6” wide cants. A dual hand control check valve requires that the operator has both hands on the push buttons while the table is moving through the cutter. Automatic pallet notcher wood pallet notching machine completely simulates the real process of the grooving process and practical application, and continuously improves and perfects according to the feedback from customers.
