55kW Coconut Fiber rotary drying machine For Dry Plant Fibers

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Strong wooden pallet for global shipping Delivery Time : 10-120 working days
Payment Terms : L/C, D/A, Western Union, MoneyGram Supply Ability : 10 sets per month
Place of Origin: China Brand Name: ThoYu
Certification: CE Model Number: TYXG2336

Detail Information

Name: Coconut Fiber Rotary Drum Drying Machine Raw Material Moisture: 30-45%
Drying Moisture: 15-18% Total Power: 40-55 KW
Application: Dry Plant Fibers Covering Area: 10m*50m
High Light:

Coconut Fiber Rotary Drying Machine

,

55kW rotary drying machine

,

Rotary Drum Drying Machine

Product Description

Coconut Fiber Rotary Drum Drying Machine For Dry Plant Fibers



We research and develop the coconut fiber rotary drum drying machine, direct docking coconut fiber separator, dry shredded coconut, coconut chaff sorting, desalting and dewatering, and drying a complete process within 40 minutes. Coconut fiber rotary drum drying machine is energy conservation and environmental protection. The quality of coconut and coconut chaff can be guaranteed. After high-temperature treatment, coconut pith and coconut fiber get cleaner. The production line of the necessary equipment for the coconut pith and coconut fiber is mechanized with large-scale and intensive production.



The dedicated coconut fiber rotary drum drying machine also is known as a coconut fiber dryer. It is mainly composed of a hot blast stove, feed conveyor, rotary drum dryer, discharge conveyor, dust collector, power distribution cabinet. After the separation of fiber entering the coconut fiber rotary drum drying machine, it is uniformly distributed in the drum, lifting the material and drop it through the hot air in order to maximize heat transfer. The material is evenly dispersed in the hot air, heat transfer, mass transfer thus dries quickly in the drum. The production line of process parameters, equipment selection, and structure design is analyzed for the characteristics of coconut fiber material and the actual shredded coconut fiber drying test validation. In the schematic design, fully consider the silk fiber is flammable, easy cluster, the characteristics of furfural residue, we adopted a series of innovative technology and unique technology in order to ensure good silk fiber drying effect and cleanliness.



Coconut fiber rotary drum drying machine parameter



Model Capacity(t/h) Raw Material Moisture(%) Drying Moisture(%) Drying temperature(℃) Total Power(kw) Total Weight(kg) Covering Area
TYXG1416 0.3-0.5 30-45 15-18 100-180 20-35 12000 8m*24m
TYXG1620 0.4-0.6 25-40 18000 8m*30m
TYXG1824 0.5-0.7 30-45 24000 8m*38m
TYXG2230 0.8-1.0 35-50 30000 10m*46m
TYXG2336 1.2-1.5 40-55 38000 10m*50m



55kW Coconut Fiber rotary drying machine For Dry Plant Fibers 0



Coconut fiber rotary drum drying machine features

  1. Frequency controlled motor speed and automatic temperature control system is used according to the raw material moisture content and parameters, to achieve the required drying effect.
  2. With the fiber slag cleaning device, shredded coconut fiber is wrapped with furfural slag to refine and separate the pure material with a complete clean drying process, thus the finished fiber is much pure.
  3. The manufacturing of modular design, firm structure, convenient installation, no fragile parts, low maintenance cost, and long service life.
  4. The dryer can be attached with a fiber machine, a screening machine, a packaging machine into a coconut shell (string) drying production line.

55kW Coconut Fiber rotary drying machine For Dry Plant Fibers 1
