Saw Length 2500mm Cutting Big Log Horizontal Wood Bandsaw

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Strong wooden pallet for global shipping Delivery Time : 10-120 working days
Payment Terms : L/C, D/A, Western Union, MoneyGram Supply Ability : 20 sets per month
Place of Origin: China Brand Name: ThoYu
Certification: CE Model Number: TYMJ-2500

Detail Information

Product Name: Big Wood Log Band Saw Saw Width: < 2500 Mm
Saw Height: < 2200 Mm Saw Thickness: < 400 Mm
Saw Wheel Diameter: 1070 Mm Saw Blade Length: 10300 Mm
High Light:

Log Horizontal Wood Bandsaw


2500mm Horizontal Wood Bandsaw


Band Saw For Cutting Logs

Product Description

Max Saw Length 2500 Mm Big Wood Log Band Saw Cutting Machine


Big wood log band saw is our patented product, it is easy to install and operate, smooth finishing by carbide band saw blade, the cutting kerf is small, reduce the waste to high output, which is suitable for cutting expensive wood in the furniture factory and move around to cut wood in virgin forest.


The movement of the big wood log band saw is operated by a variable-speed motor, and the speed of the movement can be flexibly adjusted according to the softness and hardness of the wood during the working process. The lifting is operated by a digital computer, and the workbench can accurately process wood according to the number of inputs. The wood processing accuracy can reach 1 mm. This big wood log band saw machine can process wood from 1 cm to 50 cm. It can be adjusted precisely as required.


Big wood log band saw parameters


Model TYMJ-1200 TYMJ-1500 TYMJ-2000 TYMJ-2500
Max Sawing Width 1200 mm 1500 mm 2000 mm 2500 mm
Max Sawing Height 1200 mm 1500 mm 1700 mm 2200 mm
Saw wheel diameter 960 mm 1000 mm 1070 mm 1070 mm
Max Sawing thickness 350 mm 350 mm 400 mm 400 mm
Sawing wood Length 6 m 6 m 6 m 6 m
Saw Blade Length 7700 mm 8300 mm 9300 mm 10300 mm
Motor Power 30 kW 37 kW 45 kW 45 kW
Weight 3800 kg 4500 kg 5000 kg 5500 kg
Option: Add Rail Frame for easy move around in different places.


Saw Length 2500mm Cutting Big Log Horizontal Wood Bandsaw 0


Big wood log band saw features

  1. After turning, cylindrical, grinding, chroming the stand columns is smooth and precise. the copper sliding bush is wear-resisting.
  2. Counterweight steel makes the blades more flexible and not easy to break.
  3. High quality parts, SKF Bearings From Sweden.
  4. After dynamic balance correcting, The wear-resistant band saw wheel working smoothly.
  5. 1-20 m/min. Variable Frequency speed adjustable forward/backward, the forward speed will be 1-20 meters/minute
  6. The machine was driven by electric engine
  7. Touch screen setting sawing thickness


Saw Length 2500mm Cutting Big Log Horizontal Wood Bandsaw 1


Saw Length 2500mm Cutting Big Log Horizontal Wood Bandsaw 2
